Oceancartz 48V 105Ah Lithium Golf Cart Battery with 58V Charger

• Rated Capacity: 105 AH
• Nominal Voltage: 51.2 V
• Energy: 5529 WH
• Charging Voltage: 58 V
• Voltage at End of Discharge: 40 V
• Charging Protection Voltage: 59.2 V
• Standard Charge Current: 10 A
• Fast Charge Current: 20 A
• Max Continuous Charge Current: 30 A
• Standard Discharge Current: 50 A
• Fast Discharge Current: 100 A
• Max Continuous Discharge Current: 150 A
• Over Discharge Current: 480 A (for 18 seconds)
• AC Impedance: ≤50 mΩ
• Operation Temperature (Charge): 0°C to 45°C
• Operation Temperature (Discharge): -10°C to 60°C
• Dimensions (L x W x H): 470 mm x 305 mm x 245 mm
• Weight: 45 kg (99.2 lbs)

The battery delivers a nominal voltage of 51.2V throughout the discharge cycle until it reaches the 40V end of discharge limit. The unit outputs a continuous discharge current of up to 150 A for standard vehicle operation. For situations requiring higher power draw, the battery is rated to supply an over-discharge current of 480 A for a maximum duration of 18 seconds. The AC impedance measures at ≤50 mΩ, which dictates the energy flow efficiency during charge and discharge cycles. The battery operates within a temperature range of -10°C to 60°C during vehicle use. The unit weighs 45 kg, altering the total weight of the golf cart based on the configuration of the removed battery system.

This Oceancartz lithium battery functions as a direct power supply for 48V electric vehicles. The integrated battery management system automatically regulates charging and discharging, stopping the charge at 59.2V and cutting off the discharge at 40V to maintain the specified operating parameters. The package includes both the 105AH battery unit and the compatible 58V charger, providing the necessary technical components for installation and immediate operation. The physical dimensions of 470 mm x 305 mm x 245 mm are compatible with standard 48V golf cart battery compartments. The sealed construction requires no routine water maintenance or terminal cleaning.

Your investment is fully protected with Oceancartz. We provide a comprehensive 5-year warranty and service guarantee on our 48V 105AH lithium battery, ensuring your electric golf cart remains powered for years to come.
